|Port Size:||1/8"||Body Mateial:||Aluminium Alloy|
|Working Pressure:||5 Bar To 10 Bar||Working Temperature:||-40° To +80°|
combination Control Valve,
automatic control valves
Tipper Air Control Valves are designed to enable easy controls of hydraulic functions as well as controlling air from the cabin of vehicles.
These are manufactured by adhering to preset industry norms and are compatible with makes of major vehicle manufacturers.
1) Power: Hydraulic
2) Material: Aluminum
3) Automatically locked in stop and fall position
4) Working medium:Air
5) Operating pressure(Bar): up to 12
6) Working temperature: -40℃-/+80℃
7) Nominal diameter(mm) 4
8) Weight: 0.6kg
1.Body Material: Aluminum
2.Seal Material: HNBR
3.Working Pressure: 0.5-12 Bar
4.Ambient temperature: -55℃-180℃
5.Port Size: M10*1
6.Automatically locked in stop and fall position
8.Able to coordinate with the Pneumatic control valve
9. Small Operating force
11.Easy to install
12..Long service life
Mounting of the air control:
When the air control is mounted next to the drivers seat a strong support should be used.
Available supports are:
- 092 32 002 for on-seat mounting
- 092 05 002 for on-floor mounting
Use always rubber grommets to protect air tubes and to prevent that dust and water enters the cabin.
For trouble free life of the entire pneumatic system the air system must be free from water.
The air control should be mounted in such a way that:
1 it is easy to reach by the operator.
2 it is no obstacle when entering or leaving the cabin.
3 it is clear from any moving parts such as drivers seat and closed door.
The air exhaust connection must be brought outside the
cabin to prevent air entering the cabin, which gives the following disadvantages:
2 blown up sand and dust
3 when alcohol is used to prevent the pneumatic system against frost the alcohol vapour will enter the cabin
o Make sure that air tubes:
1 are not too close to sharp objects.
2 are clear from moving parts.
3 are clear from exhaust and compressor lines.
4 can not get kinked.
5 are not too long.
note: The air supply must always be tapped off from a accessory air tank or auxiliary valve and the
pneumatic system must be protected with a charging valve.
( see guide - lines from truck manufacturer )
For operation of the air control see the Hyva
operation and maintenance instructions
The air supply must always be taken from an accessory air tank or auxiliary valveand the pneumatic system must be protected with a charging valve.
